Specification Matrices
Everything you need to know, BTUs, sizes, venting and CAD download files.
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| eReflex 105R |
|
1100 |
380 |
No Vent |
No Vent |
|
|
|
|
| Onyx 110RW |
|
1188 |
443 |
No Vent |
No Vent |
|
|
|
|
| eReflex 110W |
|
1100 |
352 |
No Vent |
No Vent |
|
|
|
|
| eReflex 135R |
|
1400 |
380 |
No Vent |
No Vent |
|
|
|
|
| Onyx 150RW |
|
1518 |
443 |
No Vent |
No Vent |
|
|
|
|
| Onyx 190RW |
|
1968 |
443 |
No Vent |
No Vent |
|
|
|
|
| eStudio ES105R |
|
1036 |
330 |
No Vent |
No Vent |
|
|
|
|
| eStudio ES135R |
|
1336 |
330 |
No Vent |
No Vent |
|
|
|
|
| eStudio ES165R |
|
1574 |
330 |
No Vent |
No Vent |
|
|
|
|
| eStudio ES60R |
|
600 |
600 |
No Vent |
No Vent |
|
|
|
|
| eStudio ES85R |
|
836 |
330 |
No Vent |
No Vent |
|
|
|
|
| Riva GER670V |
|
682 |
565 |
No Vent |
No Vent |
|
|
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| Ei25 |
|
635 |
406 |
No Vent |
No Vent |
|
|
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| City Series™ Chicago Corner 40LE |
30 |
1219 |
946 |
Direct Vent |
Top Vent |
175mm |
102mm |
|
|
| City Series™ Chicago Corner 40RE |
30 |
1219 |
946 |
Direct Vent |
Top Vent |
175mm |
102mm |
|
|
| City Series™ Chicago Corner 60 |
41 |
1810 |
990 |
Direct Vent |
Top Vent |
203mm |
127mm |
|
|
| Greenfire® GF1500L |
50 |
1359 |
737 |
Direct Vent |
Top Vent |
203mm |
127mm |
|
|
| Greenfire® GF1500LST |
50 |
1439 |
844 |
Direct Vent |
Top Vent |
203mm |
127mm |
|
|
| Greenfire® GF950L |
35 |
1091 |
725 |
Direct Vent |
Top Vent |
175mm |
102mm |
|
|
| Greenfire® GFi750ZC |
26 |
710 |
798 |
Direct Vent |
Top Vent |
76mm |
100mm |
|
|
| City Series™ New York View 40 |
30 |
1175 |
946 |
Direct Vent |
Top Vent |
175mm |
102mm |
|
|
| City Series™ New York View 60 |
41 |
1668 |
999 |
Direct Vent |
Top Vent |
203mm |
127mm |
|
|
| Panorama® PG36 |
33 |
914 |
775 |
Direct Vent |
Top Vent |
175mm |
102mm |
|
|
| City Series™ San Francisco Bay 40 |
30 |
1231 |
946 |
Direct Vent |
Top Vent |
175mm |
102mm |
|
|
| City Series™ San Francisco Bay 60 |
41 |
1810 |
990 |
Direct Vent |
Top Vent |
203mm |
127mm |
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| FG39 |
40 |
660 |
762 |
Direct Vent |
Top Vent |
175mm |
102mm |
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| DVi34L |
32 |
680 |
586 |
Direct Vent |
Top Vent |
76mm |
76mm |
|
|
| Greenfire® GFi750 |
26 |
685 |
590 |
Direct Vent |
30 Degree |
76mm |
100mm |
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| Gemfire HZO42 |
47 |
1099 |
527 |
No Vent |
No Vent |
|
|
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| Mansfield |
|
1073 |
927 |
Double Wall Pipe |
Top Vent |
N/A |
175mm |
|
|
| Montrose |
|
1090 |
901 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Studio STV2C |
|
940 |
443 |
Double Wall Pipe |
Top Vent |
N/A |
153mm |
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| Albany |
|
688 |
792 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Alterra |
|
726 |
872 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Cardinia |
|
585 |
692 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Gosford |
|
794 |
902 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Hamilton |
|
610 |
922 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Hume |
|
769 |
859 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Narrabri |
|
490 |
679 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Renmark |
|
640 |
712 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Studio STV2F |
|
1000 |
504 |
Double Wall Pipe |
Top Vent |
N/A |
153mm |
|
|
| Windsor |
|
610 |
922 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Model |
Nominal Max. Gas Consumption (MJ) |
Width (front) |
Height |
Vent Type |
Vent Location |
Vent Size (Air Intake) |
Vent Size (Exhaust) |
CAD files |
BIM files |
| Bellerive |
|
699 |
597 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
| Berwick |
|
640 |
589 |
Double Wall Pipe |
Top Vent |
N/A |
152mm |
|
|
